8-channel ICSLan Input/Output Interface

Model: EXB-I/O8
Part #: FG2100-21
  • Designed for use with single strand multimode fiber; the most common, easily terminated and installed fiber cable solution
  • Compatible DGX Fiber Receivers feature SmartScale™ Technology which automatically responds to the display's declared EDID information and scales the video to the best resolution and video parameters for that display without manual setup
  • DGX Technology offers simple signal conversion between analog and digital signals whether it is needed at the source, the switch or the destination
  • Use in conjunction with our DGX Fiber Transmitters and Receivers to send video, audio and one-way control over a single fiber cable up to 6,000 feet – 3,000 feet to the matrix switcher and 3,000 feet after the matrix switcher
  • Supports matrix switching of embedded digital or analog audio and one-way control when used in conjunction with any DGX Fiber TX / RX pair running through the Epica DGX 144 SC Fiber Input and Output Boards
Project List
Product Info
Tech Specs
Related Products
Documents
OVERVIEW

ICSLan Device Control Boxes allow users to manage devices remotely from a Controller over an Ethernet network. This provides a beautifully simple method for a centralized control environment allowing users to share a controller among multiple smaller rooms versus controllers in every room. Ethernet has become the industry standard for connecting devices and the ICSLan Device Control Boxes make it easy to introduce control to equipment such as projectors located extended distances from a Controller. Additionally, the number of ports on an AMX Controller can be expanded when all ports are fully populated. Because they employ Native NetLinx technology, it is extremely simple to add an EXB to an AMX installation.

COMMON APPLICATIONS

Conference rooms, classroom or auditoriums where a single controller is used to manage multiple devices such as projectors spread throughout a facility or to add additional ports to an AMX Central Controller.

  • Designed for use with single strand multimode fiber; the most common, easily terminated and installed fiber cable solution
  • Compatible DGX Fiber Receivers feature SmartScale™ Technology which automatically responds to the display's declared EDID information and scales the video to the best resolution and video parameters for that display without manual setup
  • DGX Technology offers simple signal conversion between analog and digital signals whether it is needed at the source, the switch or the destination
  • Use in conjunction with our DGX Fiber Transmitters and Receivers to send video, audio and one-way control over a single fiber cable up to 6,000 feet – 3,000 feet to the matrix switcher and 3,000 feet after the matrix switcher
  • Supports matrix switching of embedded digital or analog audio and one-way control when used in conjunction with any DGX Fiber TX / RX pair running through the Epica DGX 144 SC Fiber Input and Output Boards
  • Supports analog video resolutions and DVI resolutions up to 1920 x 1200 @ 60Hz
  • True uncompressed DVI digital matrix switching ensures the purity of the digital image is never compromised
  • Pre-loaded with the most common EDID settings on each of the matrix switcher's input connectors to emulate the display's response when queried, which ensures transmission of the video from the source device
  • Custom EDID settings can be loaded on each input with the use of the included EDID Programmer
  • Standard RS-232 control port
  • Standard USB (mini-B) port can be used as a virtual Com port for serial communication with a PC
  • Supports AutoPatch's simple BCS serial control protocol
  • Standard Integrated TCP/IP APWeb control
  • Ships with free AutoPatch matrix switcher configuration software
  • Ships with free APControl to provide easy single-user PC control of the matrix switcher
  • Rack mounting ears included
  • AMX limited lifetime warranty
  • Fully redundant power supplies with independent power paths for maximum reliability
  • Local presets allow quick recall of a pre-programmed set of switches with a single command; multiple presets can exist within a system at the same time
  • Global presets allow quick recall of a comprehensive snapshot of all switches
  • Dealer Benefits
    • SmartScale Technology - The Epica DGX Receivers automatically scale the video output to match the display’s preferred resolution
    • Easily Convert Between Analog and Digital Signals - DGX Technology offers simple signal conversion between analog and digital signals whether it is needed at the source, the switch or the destination
    • Field Serviceable and Upgradable - Easily add or replace I/O boards at any time after deployment - the system automatically recognizes the new configuration and activates the boards
  • Customer Benefits
    • Securely Transport AV Signals – As a fiber based product, it’s inherent features protect information from security threats while delivering visual data as it was intended
    • Perfect Reproduction of the Source Image – The DGX supports high speed digital switching 4.95 Gbps, which ensures perfect pixel for pixel reproduction of original source image for all video resolutions up to 1920x1200
    • Cost Effective Fiber Transportation Solution – The Epica DGX Fiber Matrix Switchers utilize the easy to install and terminate industry standard single strand multimode fiber to transport audio, video and control
